STR-X v1.1 Update

Download: VST3 (Windows) | VST (Windows) | Mac | GitHub Mac OSX Catalina/Big Sur and M1 Mac Support 4x oversampling with option for higher-quality, linear phase oversampling when rendering “De-kinked” preamp distortion algorithm for more accurate asymmetrical distortion Expanded range of tone controls Allow option for using v1.0 tone controls Fully resizable GUI (VST3 only)… Continue reading STR-X v1.1 Update

Re: Re-Branding

You may notice, if you’ve ever been here before today, that the site has been renamed “Arboreal Audio”. I’ve decided on this renaming for a couple of reasons, namely that the previous name of Strix Audio was too similar to pre-existing names for me to justify keeping it. If you do a search for the… Continue reading Re: Re-Branding

Custom digital guitar amp head, featuring a one-knob pedal-style distortion, pre- and power-amplifier gain stages, and a custom tone stack.

Download: v1.1 VST3 (Windows) | v1.1 VST (Windows) | v1.1 Mac

v1.0: VST/VST3 (Windows) | GitHub

The STR-X was built to be a simple but powerful, digitally-oriented guitar amp, one which isn’t based off of any pre-existing analog models. Tonally, it is capable of high gain, modest crunch, and cleaner tones with some added heat.

Mode: The Mode control in the center of the amp changes the crossover point that feeds the pre-amp distortion (after the “X” pedal-style distortion). Normal will give you a solid low-end, with retained clarity in the mids and highs even when cranked. Thick drops the crossover point lower, resulting in greater intermodulation of the distorted signal, and a fuzzy tone ready for a sludge or doom sound. Finally, Open separates all of the low-end from the mids and highs for a tight and bright tone, perfect for fast palm-muted playing or any situation where the low-end of the other two modes might be excessive.

X: This mysterious knob works like a one-knob distortion pedal (inspired by the Ibanez Tube Screamer), with filters that focus the tone on the mid-range the further it’s driven—good for an extra bump before the amp, dialing in a lead tone that cuts through everything else, or for tightening the bass on Thick mode while still remaining truly Thick.

Gain: This is the pre-amp drive section, ranging from not-quite-clean to a heavy wall of distortion. At high gain, the texture varies significantly, depending on the Mode used. This stage generates asymmetric distortion and both even and odd harmonics.

Master: This knob provides the output gain of the amp, with added distortion as well. Although not claiming to emulate any particular type of tube, it does generate the symmetric, odd-harmonic distortion you’d expect from pentode tubes. With low pre-amp gain, you can use this knob to dial in fairly clean tones down low, and bright crunch up high.
